OPERATION
OPERATION
OPERATION OF WORK EQUIPMENT
Lift arm control lever (1) and bucket control lever (2) can be used
to operate the lift arm and bucket as follows.
LIFT ARM CONTROL LEVER
NOTICE
Do not use the FLOAT position when lowering the bucket. Use the FLOAT
position when leveling, see "LEVELING OPERATIONS (PAGE 3-145)".
Position (a): RAISE
When the lift arm control lever is pulled further from
the RAISE position, the lever is stopped in this
position until the lift arm reaches the preset position of
the kickout, and the lever is returned to the HOLD
position.
Position (b): HOLD
The lift arm is kept in the same position.
Position (c): LOWER
Position (d): FLOAT
The lift arm moves freely under external force.
3 - 139
