ATTACHMENTS, OPTIONS
HANDLING MULTI FUNCTION MONO-LEVER
USING FNR SWITCH TO CHANGE BETWEEN FORWARD AND REVERSE
WARNING
When changing direction between FORWARD and REVERSE,check that the new direction of travel is safe. There is a blind spot
behind the machine, so be particularly careful when changing direction to travel in reverse.
When the directional selector switch actuation switch is at the ON position, if the directional lever is operated to F or R, the
machine will travel in forward or reverse according to the operation of the directional lever, regardless of the position of the
FNR switch on the head of the multi-function lever.
Priority is given to the operation of the directional lever, so be careful when operating.
Do not switch between FORWARD and REVERSE when traveling at high speed.
When switching between FORWARD and REVERSE, depress the brake to reduce the travel speed sufficiently, then change the
direction of travel. (Max.speed for changing direction: 10.5 km/h (6.5 MPH))
1.
Place the directional lever at the N position.
2. Turn on directional selector switch on the right side of switching
panel that enables directional selection.
Position (a): ON
Position (b): OFF
The pilot lamp inside the switch and the directional selection pilot
lamp on the machine monitor light up, and the FNR switch is
activated.
6 - 25
