5-4
27.2 ADJUST BELT LENGTH
TO MAKE BELT SHORTER
Pull the free end of the belt at the buckle end or tongue end.
TO MAKE BELT LONGER
Set the belt holding the buckle or tongue end at right angles to
the buckle or tongue, and pull.
27.3 CHECK SEAT BELT AND MOUNTS
Check that the bolts for the seat belt mounts on the machine are
not loose. Tighten any loose bolts.
Tightening torque: 24.5 ± 5 N•m (2.5 ± 0.5 kgf•m)
If the belt is damaged or frayed, or the mounting clamps are
damaged or deformed, replace the seat belt.
27. SEAT BELT 27. SEAT BELT
AE061720
AE061730
