2-34
12.4 MOVING MACHINE OFF
WARNING
When moving the machine off, check that the area around the
machine is safe, then sound the horn before starting.
Do not allow people near the machine.
There is a blind spot behind the machine, so be particularly
careful when traveling in reverse.
1. Check that caution pilot lamp 1 is not lighted up.
2. Set safety lock 3 of work equipment control lever 2 to the FREE
position.
3. Operate work equipment control lever 2 to raise the bucket 25
– 45 cm (10 – 18 in) from the ground, then tilt the bucket back.
4. Depress brake pedal 4, then pull parking brake release lever 5
back to release the parking brake.
If the parking brake is still locked, the machine will not move
even if the directional lever is operated. (It is equipped with a
mechanism to prevent the parking brake from dragging.)
12. OPERATION 12. OPERATION
To Next Page
