3.
When “Do you send Numeric Input?” is displayed, press
ENTER switch (4) again.
The input value will be sent out.
REMARK
To cancel the transmission, press RETURN switch (3).
The input value is cleared.
REMARK
If the message is replied, “Numeric Input (Done)” is displayed
for it.
OTHER FUNCTIONS OF MACHINE MONITOR
Confirming method of the service meter and odometer with the starting switch
in OFF position.
NOTICE
When machine is not under following operation, if the service meter and odometer monitor are dis-
played with the starting switch in OFF position, the machine probably has a failure, so ask your Komat-
su distributor for inspection.
The service meter and odometer can be displayed even if the machine monitor is not turned on.
1.
Press UP switch (1) while holding down DOWN switch (3)
with the starting switch in OFF position.
Service meter (A) and odometer (B) are displayed while
both switches are held down.
EXPLANATION OF COMPONENTS OPERATION
3-104
