bizhub PRO C6500 / bizhub PRO C6500e 4-49

3 Withdraw the carriage by holding its

handle.

– Be sure to withdraw the carriage

straightforward, and do not

change the direction forcibly

while driving it.

4 Remove the sheets from the

carriage.

The stacker unit can be removed

from the carriage.

5 Return the carriage to its original

position, then close the large

capacity stacker door.
