KTM 390 Duke Series 2019 User Manual

9 RIDING INSTRUCTIONS
100
– If the engine stalls (e.g. at a crossroads), just pull the clutch
lever and press the electric starter button. You do not have to
shift into neutral.
– If the oil pressure warning lamp lights up during a trip, stop
immediately and switch off the engine. Contact an authorized
KTM workshop.
– If the malfunction indicator lamp lights up during a trip,
please contact an authorized KTM workshop as soon as possi-
ble.
– If the general warning lamp lights up during a trip, an oper-
ating safety (warning) message was detected.
Info
All warnings which have occurred are displayed and
stored in the Warning menu until these are no longer
active.
9.5 Applying the brakes
Warning
Danger of accidents Moisture and dirt impair the brake system.
– Brake carefully several times to dry out and remove dirt from the brake linings and the brake discs.

KTM 390 Duke Series 2019 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Torque	37 Nm @ 7, 000 rpm
Compression Ratio	12.6:1
Transmission	6-speed
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Wheelbase	1, 357 mm
Seat Height	830 mm
Ground Clearance	170 mm
Fuel Tank Capacity	13.4 liters
Dry Weight	149 kg
Power	32 kW (43.5 hp) @ 9, 000 rpm
Fuel System	Electronic fuel injection (EFI)
Front Brake	320 mm disc brake
Rear Brake	230 mm disc brake
ABS	Bosch 9.1MB two-channel ABS
Engine Type	Single-cylinder, 4-stroke, liquid-cooled
Clutch	Wet multi-disc clutch, mechanically operated
