KTM 390 Duke Series 2019 User Manual

WHEELS, TIRES 14
155
14.1 Removing the front wheel
Preparatory work
– Raise the motorcycle with the rear lifting gear. ( p. 116)
– Lift the motorcycle with the front lifting gear. ( p. 117)
F00863-10
Main work
–
Remove screws
1
with washers and push the fender slightly
to the side.
–
Remove screw
2
and pull wheel speed sensor
3
out of the
hole.
–
Loosen screw
4
by several rotations.
–
Loosen screws
5
.
–
Press on screw
4
to push the wheel spindle out of the axle
clamp.
–
Remove screw
4
.
Warning
Danger of accidents Damaged brake discs reduce the
braking effect.
– Always lay the wheel down in such a way that the
brake disc is not damaged.
– Hold the front wheel and remove the wheel spindle. Take the
front wheel out of the fork.

KTM 390 Duke Series 2019 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Torque	37 Nm @ 7, 000 rpm
Compression Ratio	12.6:1
Transmission	6-speed
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Wheelbase	1, 357 mm
Seat Height	830 mm
Ground Clearance	170 mm
Fuel Tank Capacity	13.4 liters
Dry Weight	149 kg
Power	32 kW (43.5 hp) @ 9, 000 rpm
Fuel System	Electronic fuel injection (EFI)
Front Brake	320 mm disc brake
Rear Brake	230 mm disc brake
ABS	Bosch 9.1MB two-channel ABS
Engine Type	Single-cylinder, 4-stroke, liquid-cooled
Clutch	Wet multi-disc clutch, mechanically operated
