15 ELECTRICAL SYSTEM
184
15.9 Diagnostics connector
H01906-10
Diagnostics connector
1
is located under the passenger seat.
15.10 Front ACC1 and ACC2
E01189-10
Installation location
–
Power supplies ACC1
1
and ACC2
2
front are located on
the left of the vehicle, behind the cover under the fuel tank.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KTM 390 Duke Series 2019 and is the answer not in the manual?

KTM 390 Duke Series 2019 Specifications

General IconGeneral
Displacement373.2 cc
Bore x Stroke89 mm x 60 mm
Torque37 Nm @ 7, 000 rpm
Compression Ratio12.6:1
Transmission6-speed
FrameSteel trellis frame, powder coated
Front SuspensionWP upside-down Ø 43 mm
Rear SuspensionWP monoshock
Front Tire110/70 R17
Rear Tire150/60 R17
Wheelbase1, 357 mm
Seat Height830 mm
Ground Clearance170 mm
Fuel Tank Capacity13.4 liters
Dry Weight149 kg
Power32 kW (43.5 hp) @ 9, 000 rpm
Fuel SystemElectronic fuel injection (EFI)
Front Brake320 mm disc brake
Rear Brake230 mm disc brake
ABSBosch 9.1MB two-channel ABS
Engine TypeSingle-cylinder, 4-stroke, liquid-cooled
ClutchWet multi-disc clutch, mechanically operated
