KTM 390 Duke Series 2019 User Manual

CONTROLS 6
29
F00785-10
Overview of the left combination switch
1
Light switch ( p. 29)
2
Menu switch ( p. 30)
3
Turn signal switch ( p. 30)
4
Horn button ( p. 31)
6.4.2 Light switch
F00786-10
Light switch
1
is fitted on the left side of the handlebar.
Possible states
Low beam on – Light switch in position
A
. In this
position, the low beam and the tail light are switched
on.
High beam on – Push the light switch to position
B
.
In this position, the high beam and the tail light are
switched on.
Headlight flasher – Push the light switch into posi-
tion
C
.

KTM 390 Duke Series 2019 Specifications

General

Displacement	373.2 cc
Bore x Stroke	89 mm x 60 mm
Torque	37 Nm @ 7, 000 rpm
Compression Ratio	12.6:1
Transmission	6-speed
Frame	Steel trellis frame, powder coated
Front Suspension	WP upside-down Ø 43 mm
Rear Suspension	WP monoshock
Front Tire	110/70 R17
Rear Tire	150/60 R17
Wheelbase	1, 357 mm
Seat Height	830 mm
Ground Clearance	170 mm
Fuel Tank Capacity	13.4 liters
Dry Weight	149 kg
Power	32 kW (43.5 hp) @ 9, 000 rpm
Fuel System	Electronic fuel injection (EFI)
Front Brake	320 mm disc brake
Rear Brake	230 mm disc brake
ABS	Bosch 9.1MB two-channel ABS
Engine Type	Single-cylinder, 4-stroke, liquid-cooled
Clutch	Wet multi-disc clutch, mechanically operated
