OPERATING ELEMENTS 12
Light switch (EVERY XCR-W MODELS)
500146-10
The light switchb is on the right of the speedometer.
Possible states
(XCR-WbZA)
• Light off ದbLight switch is pressed in up to the stop. In this position, the light
is switched off.
• Light on ದbLight switch is pulled out to the stop. In this position, the low beam
and tail light are switched on.
(XCR-WbUSA)
• The light switch has no function when delivered. ದbIt can be used if lighting is
fitted later.
Light switch (EXC-RbUSA)
500142-10
The light switchb is fitted on the left side of the handlebar.
Possible states
Low beam on ದbLight switch is turned downwards. In this position, the
low beam and tail light are switched on.
High beam on ದbLight switch is turned upwards. In this position, the high
beam and the tail light are switched on.
Headlight flasher switch (EXC-RbUSA)
500143-10
The headlight flasher switchb is fitted on the left side of the handlebar.
Possible states
• Headlight flasher switch in neutral position
• Headlight flasher switch pressed ದbIn this position, the headlight flasher (high
beam) is actuated.
Horn (EXC-RbEU, EXC-RbAUS/UK, EXC-RbSIXbDAYS)
500134-11
The horn buttonb is fitted on the left side of the handlebar.
Possible states
• Horn buttonb in neutral position
• Horn buttonb pressed ದbThe horn is operated in this position.
Horn (EXC-RbUSA)
500142-11
The horn buttonb is fitted on the left side of the handlebar.
Possible states
• Horn buttonb in neutral position
• Horn buttonb pressed ದbThe horn is operated in this position.
