MAINTENANCE WORK ON CHASSIS AND ENGINE 82
200116-10
Condition
Engine is cold.
ದ Remove gear oil level check screwb
. Stand the vehicle upright.
ದ Check the gear oil level.
A small amount of gear oil should flow out.
» If no gear oil flows out:
ದ Top up with gear oil. ( P. 83)
ದ Mount and tighten the gear oil level check screw.
Specification
Screw, gear oil level check M6 10bNm
(7.4blbfbft)
Changing gear oil, cleaning gear oil screenbx
ದ Drain the gear oil and clean the gear oil screen. ( P. 82)
ದ Fill up with gear oil. ( P. 83)
Draining gear oil, cleaning gear oil screenbx
Warning
Danger of scaldingಘEngine oil and gear oil get very hot when the motocycle is driven.
ದ Wear suitable protective clothing and gloves. If you scald yourself, hold the affected area under cold water immediately.
Warning
Environmental hazardಘProblem materials cause environmental damage.
ದ Dispose of oil, grease, filters, fuel, cleaning substances, brake fluid, batteries, etc. according to regulations.
Info
Drain the gear oil only when the engine is warm.
ದ Stand the motorcycle on its side stand on a horizontal surface.
500159-10
ದ Place a suitable container under the engine.
ದ Remove the gear oil drain plugb
.
ದ Remove the gear oil screen plugb
.
ದ Completely drain the gear oil.
ದ Thoroughly clean the gear oil drain plug with a magnet.
ದ Thoroughly clean the drain plug and gear oil screen with a magnet.
ದ Clean the sealing surface on the engine.
ದ Check parts for damage and wear. Replace damaged or worn parts.
ದ Refit gear oil drain plugb
with seal ring and tighten it.
Specification
Gear oil drain plug with magnet M12x1,5 20bNm
(14.8blbfbft)
ದ Fit the plugb
for the gear oil screen and tighten it.
Specification
Plug, gear oil screen M16x1,5 20bNm
(14.8blbfbft)
