KTM 450 EXC-R EU User Manual

MAINTENANCE WORK ON CHASSIS AND ENGINE 42
100023-11
(EXC-RbEU, EXC-RbAUS/UK, EXC-RbUSA, XCR-WbZA)
ದ Loosen screwb
. Remove the fork leg on the left.
ದ Loosen screwb
. Remove the fork leg on the right.
Installing the fork legsbx
100021-10
ದ Check parts for damage and wear. Replace damaged or worn parts.
ದ Position the fork legs.
Info
The topmost sunk nut in the fork leg must be flush to the upper edge of the
upper triple clamp.
Position the bleeder screwb
 to the front.
500094-11
(EXC-RbSIXbDAYS, XCR-WbUSA)
ದ Fully tighten screwb
.
Specification
Screw, top triple clamp M8 17bNm
(12.5blbfbft)
ದ Fully tighten screwb
.
Specification
Screw, bottom triple clamp M8 12bNm
(8.9blbfbft)
100023-10
(EXC-RbEU, EXC-RbAUS/UK, EXC-RbUSA, XCR-WbZA)
ದ Fully tighten screwb
.
Specification
Screw, top triple clamp M8 20bNm
(14.8blbfbft)
ದ Fully tighten screwb
.
Specification
Screw, bottom triple clamp M8 15bNm
(11.1blbfbft)
500093-11
ದ Position brake caliper, mount and tighten screwsb.
Specification
Screw, front brake caliper M8 25bNm
(18.4blbfbft)
Loctite
®
243™
ದ Fit cable clipb
.
ದ Position the brake line and cable harness. Put the clamp on, mount and tighten
screwsb
.
ದ Fit front wheel. ( P. 64)
