OPERATING
ELEMENTS
23
ದ
Insert
the
key
in
the
steering
lock,
turn
it
to
the
left,
press
it
in
and
turn
it
to
the
right.
Remove
the
key.
Steering
is
no
longer
possible.
Info
Never
leave
the
key
in
the
steering
lock.
Unlocking
the
steering
(EXC-R
b
EU,
EXC-R
b
AUS/UK,
EXC-R
b
USA)
ದ
Insert
the
key
in
the
steering
lock,
turn
it
to
the
left,
pull
it
out
and
turn
it
to
the
right.
Remove
the
key.
You
can
now
steer
the
bike
again.
Info
Never
leave
the
key
in
the
steering
lock.
24
26
