MAINTENANCE WORK ON THE CHASSIS 35
10.18Dismounting the front fender
700414-10
– Remove screws . Remove the front fender.
10.19Installing the front fender
700415-01
– Position the fender with holding lugs  into the drill holes on the start number
plate.
700414-11
– Position the front fender. Mount and tighten screws .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
10.20Removing the seat
300633-10
– Open quick release  and raise the rear of the seat.
– Pull back the seat and remove it.
10.21Mounting the seat
300634-10
– Hook the seat onto screw  and lower the seat at the rear while pushing it forward.
Projection  hooks into the fuel tank.
