MAINTENANCE WORK ON THE CHASSIS 36
300633-11
– Close quick release .
10.22Removing the air filter x
Note
Engine failure Unfiltered intake air has a negative effect on the service life of the engine.
– Never ride the vehicle without an air filter since dust and dirt can get into the engine and result in increased wear.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Oil, grease, filters, fuel, cleaners, brake fluid, etc., should be disposed of as stipulated in applicable regulations.
– Remove the seat. ( p. 35)
700441-01
– Unhook the air filter holder and swing it to the side. Remove the air filter with
the air filter support.
– Remove the air filter from the air filter support.
10.23Installing the air filter x
100818-10
– Mount the clean air filter onto the air filter support.
– Grease the air filter in area .
Long-life grease ( p. 84)
700441-01
– Put in both parts together, position them and fix them with the air filter support .
Info
If the air filter is not correctly mounted, dust and dirt can penetrate into the
engine and can cause damage.
– Mount the seat. ( p. 35)
