KTM 65 SX 2012 - Greasing the Steering Head Bearing; Dismounting the Start Number Plate; Installing the Start Number Plate; Dismounting the Front Fender

MAINTENANCE WORK ON THE CHASSIS 32
10.13Greasing the steering head bearing x
300669-01
–
Remove the lower triple clamp. x ( p. 29)
–
Install the lower triple clamp. x ( p. 29)
10.14Dismounting the start number plate
B00400-10
– Remove screw  and take off clamp.
– Remove screw . Remove the start number plate.
10.15Installing the start number plate
700413-01
– Position the start number plate with the drill holes onto the holding lugs  of the
fender.
B00400-11
– Mount and tighten screw .
Guideline
Remaining screws, chassis M6 10 Nm (7.4 lbf ft)
– Position the brake line. Put the clamp on, mount and tighten screw .
10.16Dismounting the front fender
700414-10
– Remove screws . Remove the front fender.
