TECHNICAL DATA - CHASSIS TIGHTENING TORQUES 78
Spoke nipple M3.5 3 Nm (2.2 lbf ft) –
Remaining nuts, chassis M6 10 Nm (7.4 lbf ft) –
Remaining screws, chassis M6 10 Nm (7.4 lbf ft) –
Screw, ball joint of push rod on foot
brake cylinder
M6 10 Nm (7.4 lbf ft) –
Screw, foot brake cylinder M6 10 Nm (7.4 lbf ft) –
Screw, fork stub M6 10 Nm (7.4 lbf ft) –
Screw, front brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, rear brake disc M6 14 Nm (10.3 lbf ft)
Loctite
®
243™
Screw, throttle grip M6 4.5 Nm (3.32 lbf ft) –
Nut, rim lock M8 10 Nm (7.4 lbf ft) –
Remaining nuts, chassis M8 25 Nm (18.4 lbf ft) –
Remaining screws, chassis M8 25 Nm (18.4 lbf ft) –
Screw, bottom triple clamp M8 15 Nm (11.1 lbf ft) –
Screw, brake caliper M8 20 Nm (14.8 lbf ft)
Loctite
®
243™
Screw, engine bracket M8 30 Nm (22.1 lbf ft) –
Screw, foot brake lever M8 35 Nm (25.8 lbf ft)
Loctite
®
243™
Screw, handlebar clamp M8 20 Nm (14.8 lbf ft) –
Screw, rear sprocket M8 25 Nm (18.4 lbf ft)
Loctite
®
243™
Screw, tail piece M8 35 Nm (25.8 lbf ft)
Loctite
®
243™
Screw, top triple clamp M8 20 Nm (14.8 lbf ft) –
Remaining nuts, chassis M10 45 Nm (33.2 lbf ft) –
Remaining screws, chassis M10 45 Nm (33.2 lbf ft) –
Screw, bottom shock absorber M10 45 Nm (33.2 lbf ft) –
Screw, front wheel spindle M10 40 Nm (29.5 lbf ft) –
Screw, handlebar support M10 40 Nm (29.5 lbf ft)
Loctite
®
243™
Screw, top shock absorber M10 45 Nm (33.2 lbf ft) –
Nut, rear wheel spindle M12x1 40 Nm (29.5 lbf ft) –
Nut, swingarm pivot M12x1 40 Nm (29.5 lbf ft) –
Nut, steering stem M20x1.5 10 Nm (7.4 lbf ft) –
