TECHNICAL DATA - ENGINE TIGHTENING TORQUES 72

Nut, exhaust control diaphragm M5 4 Nm (3 lbf ft) –

Screw, clutch line holder M5 5 Nm (3.7 lbf ft) –

Screw, diaphragm cover of exhaust

control

M5 4 Nm (3 lbf ft) –

Screw, ignition system/stator M5 5 Nm (3.7 lbf ft)

Loctite

222

Screw, main shaft bearing retainer M5 5 Nm (3.7 lbf ft)

Loctite

648™

Screw, reed valve housing of exhaust

control

M5 5 Nm (3.7 lbf ft) –

Screw, retaining bracket for return

spring of shift shaft

M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, shift drum locating M5 6 Nm (4.4 lbf ft)

Loctite

243™

Screw, water pump wheel M5 5 Nm (3.7 lbf ft)

Loctite

243™

Drain plug, water pump cover M6 6 Nm (4.4 lbf ft) –

Screw, alternator cover M6 8 Nm (5.9 lbf ft) –

Screw, clutch intermediate cover M6 10 Nm (7.4 lbf ft) –

Screw, clutch slave cylinder M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, clutch springs M6 10 Nm (7.4 lbf ft) –

Screw, engine case M6 10 Nm (7.4 lbf ft) –

Screw, engine sprocket cover M6 10 Nm (7.4 lbf ft) –

Screw, exhaust flange M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, gear oil level check M6 6 Nm (4.4 lbf ft) –

Screw, intake flange/reed valve housing M6 10 Nm (7.4 lbf ft) –

Screw, kickstarter stop piece M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, outer clutch cover M6 10 Nm (7.4 lbf ft) –

Screw, reed valve housing of exhaust

control

M6 10 Nm (7.4 lbf ft) –

Screw, shift drum bearing retainer M6 8 Nm (5.9 lbf ft)

Loctite

243™

Screw, shift drum locating M6 10 Nm (7.4 lbf ft)

Loctite

243™

Screw, shift lever M6 14 Nm (10.3 lbf ft)

Loctite

243™

Screw, water pump cover M6 8 Nm (5.9 lbf ft) –

Vacuum connection/vent connection M6 5 Nm (3.7 lbf ft)

Loctite

243™

Screw, cylinder head M7 18 Nm (13.3 lbf ft) –

Nuts, cylinder base M8 20 Nm (14.8 lbf ft) –

Screw, kickstarter M8 25 Nm (18.4 lbf ft)

Loctite

243™

Stud, cylinder base (left section of the

engine case)

M8 Tightening sequence:

screw in until it projects by

27 mm (1.063 in)

Loctite

243™

Stud, cylinder base (right section of

the engine case)

M8 Tightening sequence:

screw in until it projects by

27 mm (1.063 in)

Loctite

243™

Screw, inner clutch hub M10 60 Nm (44.3 lbf ft)

Loctite

243™

Spark plug M10x1 10… 12 Nm (7.4…

8.9 lbf ft)

–

Nut, rotor M12x1 50 Nm (36.9 lbf ft) –

Oil drain plug with magnet M12x1.5 20 Nm (14.8 lbf ft) –

Nut, primary gear M14x1.25 40 Nm (29.5 lbf ft)

Loctite

243™
