Kubota 3220 - Component Lifespan and Service Preparation; Capillary Tube Packing: Lifetime and Replacement

４− 6
Section 4 Service
㸲㸫㸴㸬
Lifetime and Exchange Method of
the Capillary Tube Protective Packing
The rotor is equipped with a capillary tube protective packing to prevent occurrence of
damage of the capillary tube while the centrifugal operations are being carried out.
Thecapillarytubeprotectivepackingisaconsumablepart.Replaceitin3years,
approximately.
However,ifthecapillarytubeprotectivepackingiscrackedordeteriorated,breakageof
thecapillarytubecanoccurmoreeasily.Therefore,ifthecapillarytubeprotective
packingiscrackedordeteriorated,replacethecapillarytubeprotectivepackingregardless
oftheaforementionedreplacementinterval.
The exchange method of the capillary tube protective packing
(1)Removetheoldcapillarytubeprotectivepacking.
(2)Installthecapillarytubeprotectivepackingtotherotor.
(Refertothedrawingindicatedbelow)
①Wheninstallingthecapillarytubeprotectivepacking,bringthejointofthecapillarytube
protectivepackingtoapointbetweenarotorgrooveandthenextrotorgroove.
②Wheninstallingthecapillarytubeprotectivepacking,setitevenlyalongtheinner
peripheryoftherotor,payingattentionnottoletthecapillarytubeprotectivepacking
wrinkled.
Rotor
Capillary tube
protective packing
Rotor groove
When installing the capillary tube
protective packing, bring the joint of
the capillary tube protective packing to
a point between a rotor groove and
the next rotor groove.
Capillary tube
protective packing
Reverse-side
Table side
