PERIODIC SERVICE34
ENGLISH
BChecking Front PTO Belt Tension
A Always stop the engine, set the parking brake,
remove the key, and disengage the PTO lever
before working on the front PTO.
C Adjusting
If the front PTO belts slip when the PTO is operating under
load, check the front PTO belt tension and adjust the
tension spring length, as explained below.
1. Engage the PTO lever.
2. Measure tension spring length (L).
3. If (L) is shorter than 87 mm adjust it with the tension
clutch cable adjusting nut.
A (L) should be 88 to 90 mm
4. After adjustment tighten the nut securely.
A When replacing the new front PTO belts, (L) should
be 91 to 92 mm
A When replacing the front PTO belts, be sure to replace
the complete set. These belts are a matched set.
EVERY 200 HOURS AFTER 50 HOURS
BEngine Oil Filter Cartridge Change
To avoid personal injury:
A Be sure to stop the engine and remove the key
before changing the oil and the oil filter
cartridge.
A Allow engine to cool down sufficiently; oil can
be hot and may cause burns.
1. The oil filter cartridge must be changed every 200
service hours.
2. Apply a slight coat of oil onto the rubber gasket of new
cartridge.
3. To install the new cartridge, screw it in by hand. Over
tightening may cause deformation of the rubber
gasket.
4. After the new cartridge has been replaced, the engine
oil level normally lowers a little. Add engine oil to
proper level. Check for oil leaks around filter gasket.
A To prevent serious damage to the engine,
replacement element of the recommended type must
be used. Use only a genuine KUBOTA filter or its
equivalent.
(1) Adjust nut
(1) Engine oil filter cartridge
To Next Page
