50 APPENDIX
ENGLISH
APPENDIX
SOUND AND VIBRATION MEASUREMENTS
C Sound Pressure Level Measured Per EN836
C Hand/Arm Vibration Level Measured Per EN836
C Whole Body Vibration Level Measured Per EN836
A Measurement were obtained through actual field data according to STD procedure in EN836.
This value listed above represents the weighted root means square acceleration to which the whole body is subjected
on a representative machine during actual mowing and transport conditions.
The acceleration value depends upon the roughness of the ground, the speed at which the machine is operating and
the operator weight and driving habits.
Model Engine rated speed Sound pressure at the operator's position
G2160 with RCK54-24G 3200 rpm 89.5 dB (A)
Model Engine rated speed Hand/Arm vibration
G2160 with RCK54-24G 3200 rpm 1.91 m/s
Model Engine rated speed Whole body vibration
G2160 with RCK54-24G 3200 rpm 0.41 m/s
