CAB OPERATION104
BSun Roof
Raise the front loader, and visually check to see if the tip
of an attachment (bucket and fork, for example) is visible
in its position or angle from the operator’s seat.
A Open the sun roof, to allow outside air in.
BEmergency Exit
1. Open the right door of the cab if the left door is
blocked, and vice versa in an emergency situation.
2. Exit through rear window if CAB doors are blocked in
an emergency situation.
DOME LIGHT
BDome Light
Sliding the dome light switch will give the following light
condition:
A The battery will discharge if the dome light remains on.
Be sure to check the dome light switch position and/or
door closure.
WIPER
BFront Wiper / Washer Switch
1. Turn on the key switch and press the right half of the
wiper switch to the first step, the wiper is activated.
When the switch is pressed further to the second step,
washer liquid jets out.
The jetting continues while the switch is pressed and
the wiper is activated continuously.
2. Press the left half to the first step, the wiper is activated
at regular intervals.
When the switch is pressed further to the second step,
washer liquid jets out and the wiper is activated at
regular intervals.
(1) Sun roof
(2) Sun roof handle
(A) "PULL"
(B) "PUSH" (Open)
OFF ............... The light does not turn on when the
door is opened.
DOOR ........... The light turns on when the door (LH)
is opened. It turns off when the door
(LH) is closed.
ON ................ The light remains on regardless of the
door position.
(1) Dome light
(2) Dome light switch
(A) "OFF"
(B) "DOOR"
(C) "ON"
