OPERATING THE TRACTOR66
BWork Speed Display
The LCD displays both the selected speed and Auto-shift
bars.
C Selected speed display
The Auto-shift range is set to 2 shifts as standard. If "8" is
displayed at start, then the tractor starts in 8th speed and
then automatic shift-up/shift-down occurs in the range of
"8", "7", and "6". The selected speed display remains lit
when driving in 8th speed, and flashes when driving in 7th
or 6th.
C Auto-shift bar display
The auto shift bars display the set "automatic shift-down
possible speed range" and the "current speed stage". The
shift-up indicator flashes immediately before shift-up
occurs, and the shift-down indicator flashes immediately
before shift-down occurs.
C Example of Auto-shift bar display
(1) Shift-down indicator
(2) Shift-up indicator
(3) Auto-shift bar display
(4) Selected speed ("1" to "8")
No. Set shift-down range Actual speed position
(1)
2 shifts
(factory setting)
The current speed is the highest position of the set speeds.
The load and the set speed are in balance.
(2)
The current speed is shifted 1 speed down from the highest position.
The load is large and the machine is about to shift down by 1 more speed.
(3)
The current speed is shifted 2 speeds down from the highest position.
The load is light and the machine is about to shift up by 1 speed.
(4)
3 shifts
(when setting is changed)
The current speed is the highest position of the set speeds.
The load and the set speed are in balance.
(5)
The current speed is shifted 2 speeds down from the highest position.
The load is light and the machine is about to shift up by 1 speed.
(6) The current speed is shifted 3 speeds down from the highest position.
