3SPECIFICATIONS
SPECIFICATIONS
SPECIFICATION TABLE
Model
M6-101 M6-111 M6-131 M6-141
4WD
Engine
Model V3800-TIEF4 V6108-TIEF4
Type
Direct Injection, Water-cooled 4 Cycle Diesel,
Common Rail System, Turbocharger, Intercooler
Number of cylinders 4
Total displacement cm (cu.in.) 3769 (230) 6124 (374)
Bore and stroke mm (in.) 100 x 120 (3.94 x 4.72) 118 x 140 (4.65 x 5.51)
Rated revolution rpm 2600 2200
Low idling revolution rpm 800 to 850
Net power *1 kW (HP) 74.6 (100) 81.7 (109.5) 93.2 (125) 100.7 (135)
PTO power *1
(factory observed)
kW (HP) /
rpm
61.1 (82) /
2600
68.6 (92) /
2600
77.6 (104) /
2200
85.0 (114) /
2200
Battery capacity
12V, 100Ah at 20hours,
900CCA
12V, 160Ah at 20hours,
1090CCA
Fuel tank capacity L (U.S.gals.) 190 (50.2)
Engine oil capacity L (U.S.qts.) 10.5 (11.1) 14.6 (15.4)
Coolant capacity L (U.S.qts.) 10.1 (10.7) 14.6 (15.4)
DEF/AdBlue®
capacity
L (U.S.gals.) 16 (4.2)
Dimensions
Overall length mm (in.) 4200 (165.4) 4360 (171.7) <4350 (171.3)>
Overall width
(minimum tread)
mm (in.) 2100 (82.7) 2180 (85.8)
Overall height mm (in.) 2790 (109.8) 2840 (111.8) 2875 (113.2)
Wheel base mm (in.) 2435 (95.9) 2690 (105.9) <2680 (105.5)>
Tread
Front mm (in.) 1580 (62.2), 1680 (66.1) 1775 (69.9), 1875 (73.8)
Rear mm (in.)
1520 (59.8) to
2060 (81.1)
1530 (60.2) to
2040 (80.3)
1590 (62.6) to 2090 (82.3)
Crop clearance mm (in.) 370 (14.5) 425 (16.7) 450 (17.7)
Weight kg (lbs.) 4355 (9601) 4440 (9789) 4965 (10946) <5165 (11387)>
Traveling
system
Standard
tire size
Front tires 12.4R24 13.6R24 14.9R24
Rear tires 18.4R30 18.4R34 18.4R38
Clutch Multiple wet disc, Electronic Hydraulically operated
Steering Hydrostatic Power Steering
Braking system Hydraulically operated wet disk
Differential Bevel gears with differential lock (Front, Rear)
