OPERATING THE TRACTOR46
A This switch can be operated when the tractor is on the
go or at rest without depressing the clutch.
C Front wheel drive is effective for the following
jobs:
1. When greater pulling force is needed, such as working
in a wet field, when pulling a trailer, or when working
with a front-end loader.
2. When working in sandy soil.
3. When working on hard soil where a rotary tiller might
push the tractor forward.
4. For increased braking at reduced speed.
C The effectiveness of the Auto 4WD mode
5. There is no hassle of switching between 2WD/4WD.
6. In regards to rolling resistance, it is possible to reduce
tire wear and to save fuel.
7. Taking corners at high speeds can be done
effortlessly.
A Tires will wear quickly if the front wheel drive is
engaged on paved roads.
BBi-speed Turn Switch
To avoid personal injury or death:
A Do not use "Bi-speed Turn" at high speed.
A "Bi-speed Turn" enables short and fast turns,
therefore, become familiar with its performance
before operating in close or confined areas.
When 4WD indicator or Auto 4WD indicator light up, the
Bi-speed turn system works.
Press the right half;
The Auto 4WD mode activates.
The Auto 4WD mode will automatically switch
between 2WD mode and 4WD mode depending on
the travel speed.
The display indicators are as follows:
Auto 4WD
indicator
4WD
indicator
Less than
20 km/h (12.4 mph)
ON ON
More than
20 km/h (12.4 mph)
ON OFF
It returns to a central position;
The drive system returns to 2WD mode
The all indicators goes off when the system is in
2WD mode.
(1) 4WD/Auto 4WD switch
(2) 4WD indicator
(3) Auto 4WD indicator
(A) 4WD mode
(B) Auto 4WD mode
(C) 2WD mode
Press the left half;
The Bi-speed turn system activates.
The Bi-speed turn indicator come on.
It returns to a central position;
The Bi-speed turn system deactivates
The Bi-speed turn indicator goes off.
