7-S3
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
HYDRAULIC SYSTEM
3. TIGHTENING TORQUES
Tightening torques of screws, bolts and nuts on the table below are especially specified.
(For general use screws, bolts and nuts : See page G-8.)
W1018416
Item N·m kgf·m ft-lbs
Engine stop solenoid mounting screw 9.80 to 11.2 1.00 to 1.15 7.24 to 8.32
Flow priority valve mounting screw 17.7 to 20.6 1.8 to 2.1 13.0 to 15.2
Delivery hose mounting nut 24.6 to 29.4 2.5 to 3.0 14.5 to 21.6
Hydraulic pump mounting screw and nut 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Cover mounting screw 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Hydraulic cylinder assembly mounting screw and nut 39.2 to 44.1 4.0 to 4.5 28.9 to 32.5
Control valve mounting screw 23.6 to 27.4 2.4 to 2.8 17.4 to 20.2
Relief valve plug 49.0 to 68.6 5.0 to 7.0 36.2 to 50.6
To Next Page
