9-S6
F2880, F3680, RCK72-F36, RCK72R-F36, RCK60-F36, RCK60R-F36, WSM
MOWER
Greasing Spindle Shafts
1. Grease the grease nipples (1), (2) of the spindle shafts if the
amount of grease is insufficient.
W1015209
Greasing Belt Tension Pulley and Greasing Belt Tension Pivot
1. Grease the grease nipple (1) of the belt tension pulley if the
amount of grease is insufficient.
2. Grease the grease nipple (1) of the belt tension pivot if the
amount of grease is insufficient.
W1015312
(1) Grease Nipple (Bevel Gear Shaft) (2) Grease Nipple (Blade Shaft)
(1) Grease Nipple (2) Grease Nipple
To Next Page
