SERVICE INFORMATION
GENERAL INSTRUCTIONS
• All servicing operations and inspections in this section can be made with the engine installed.
• Drain the coolant before removing the right crankcase cover.
• Be careful not to drain the coolant when the engine temperature is high. (Perform this operation
when the engine is cold.)
• Drain the coolant into a clean container.
• Drain the engine oil into a clean container before removing the right crankcase cover.
• When the right crankcase cover is installed, fill with the recommended engine oil and coolant.
Then, bleed air from the water jacket.
• Refer to page 18-4 for A.C. generator inspection.
SPECIFICATIONS
Engine oil: SAE15W/40#
API-SG/CD
Oil capacity at change: 0.8 liter
Coolant: distilled water + coolant concentrate
Coolant capacity: 1165cc
SPECIAL TOOLS
Flywheel puller
Flywheel holder
SPECIFICATIONS
TORQUE VALUES
Flywheel nut : 34.3_ 44.1N-m
TROUBLESHOOTING
Refer to page 1-27 for A.C. generator troubleshooting.
Starter motor rotates but engine does not start
• Faulty starter clutch
• Starter motor rotates reversely
• Weak battery
To Next Page
