6. CYLINDER HEAD/VALVES
6-11
Bet & Win 1 25/1 50
Install a new cam chain tensioner gasket.
Release the lock pawl and push the push rod
all the way in.
Install the cam chain tensioner and tighten the
two bolts.
Install the tensioner spring and tighten the
sealing bolt.
Torque: 2.9_ 5.8N-m
CYLINDER HEAD COVER
INSTALLATION
Adjust the valve clearance. (
!
3-6)
Install a new cylinder head cover O-ring and
install the cylinder head cover.
Install and tighten the cylinder head cover
bolts.
Torque: 7.8_ 11.8N-m
Cam Chain Tensioner
Sealing Bolt
Bolt
Lock Pawl
Push Rod
Gasket
Cam Chain Tensioner
Spring
Cylinder Head Cover
O-ring
Be sure to install the O-ring into the
groove properly.
＊
