SERVICE INFORMATION
GENERAL INSTRUCTIONS
• Check the ignition system according to the sequence specified in the Troubleshooting. (
!
1-28)
• The ignition system adopts CDI unit and the ignition timing cannot be adjusted.
• If the timing is incorrect, inspect the CDI unit and A.C. generator and replace any faulty parts.
Inspect the CDI unit with a CDI tester
• Loose connector and poor wire connection are the main causes of faulty ignition system. Check
each connector before operation.
• Use of spark plug with improper heat range is the main cause of poor engine performance.
• The inspections in this section are focused on maximum voltage. The inspection of ignition coil
resistance is also described in this section.
• Inspect the ignition switch according to the continuity table specified in page
20-3.
• Inspect the spark plug referring to Section 3.
• Remove the A.C. generator and pulser coil referring to Section 10.
SPECIFICATIONS
Ignition coil resistance
(20℃ )
Pulser coil resistance (20℃ )
Exciter coil resistance (20℃ )
Ignition coil primary side max. voltage
Exciter coil max. voltage
TESTING INSTRUMENT
Electric tester
TROUBLESHOOTING
No spark at plug Engine starts but turns poorly
• Faulty spark plug • Ignition primary circuit
• Poorly connected, broken or shorted wire —Faulty ignition coil
• Faulty ignition switch —Poorly connected wire or connector
• Faulty ignition coil —Poorly contacted ignition switch
• Faulty CDI unit • Ignition secondary circuit
• Faulty A.C. generator —Faulty ignition coil
—Faulty spark plug
—Faulty high-tension wire
—Poorly insulated plug cap
• Improper ignition timing
—Faulty A.C. generator
—Stator not installed properly
—Faulty CDI unit
