FRAME COVERS REMOVAL
REAR CARRIER & HAND RAIL
REMOVAL
Remove the met-in box:
First remove the two bolts and two nuts
attaching the met-in box.
Remove the battery, C D I, fuse.
Remove the met-in box.
Remove the hand rail right and left lock hex
bolts.
Remove the four hex bolts
Remove the rear carrier and hand rail.
FRAME BODY COVER REMOVAL
Remove the one screws on the bottom of the
center cover.
Remove the center cover.
Remove the two screws attaching the front
part of the frame body cover.
Remove the right and left screws on the rear
part of the frame body cover.
Disconnect the seat lock wire.
Remove the frame body cover.
