19. SWITCHES/HORN/FUEL UNIT/THERMOSTATIC SWITCH
/TEMPERATURE GAUGE/INSTRUMENTS/LIGHTS
19-2
Bet & Win 1 25/1 50
SERVICE INFORMATION
GENERAL INSTRUCTIONS
After installation of each switch, a continuity check must be performed. A continuity check can
usually be made without removing the part from the motorcycle.
TESTING INSTRUMENT
Electric tester
SPECIAL TOOL
Fuel unit wrench
TROUBLESHOOTING
Lights do not come on when ignition Temperature gauge does not register
switch is “ON” correctly
Burned bulb Faulty temperature gauge
Faulty switch Faulty thermosensor
Poorly connected, broken or shorted wire Broken or shorted wire between
temperature gauge and thermosensor
Fuel gauge pointer does not move or
register correctly
Faulty fuel gauge
Faulty fuel unit
Poorly connected wire between fuel
gauge and fuel unit
Fuse burned out
SPECIFICATIONS
Fuse 20A
Headlight bulb 12V 35W/35W
Turn signal light bulb 12V 10W
Stoplight/taillight 12V 21/5W
License plate light 12V 5W
Instrument light 12V 1.7W
Position light 12V 5W
Turn signal indicator light 12V 3.4W
