17. IGNITION SYSTEM
17-5
Bet & Win 1 25/1 50
CDI UNIT
RESISTANCE INSPECTION
Measure the resistance between the terminals.
Replace the CDI unit if the readings are not
within the specifications in the table below.
Use the x KW range for the Sanwa Tester.
Use the x 100W range for the Kowa Tester.
Unit: KW
(+)Probe
(-)Probe
SW
(Black/White)
EXT
(Black/Red)
PC
(Blue/Yellow)
E Å Ç
(Green •
Green/White)
IGN
(Black/Yellow)
SW
(Black/White)
∞
∞
∞
∞
EXT
(Black/Red)
1-10
Needle
swings then
returns
Needle
swings then
returns
∞
PC
(Blue/Yellow)
5-50
30-100
20-80
∞
E Å Ç
(Green •
Green/White)
5-20
1-10
5-40
∞
IGN
(Black/Yellow)
∞
∞
∞
∞
IGN
(Black/Yellow
)
PC
(Blue/Yellow)
EXT
(Black/Red)
SW
(Black/White)
E Ç
(Green/White
)
E Å
(Green)
• Due to the semiconductor in circuit, it
is necessary to use a specified tester
for accurate testing. Use of an
improper tester in an improper range
may give false readings.
• Use a Sanwa Electric Tester (07308-
0020000) or Kowa Electric Tester
(TH-5H).
• In this table, “Needle swings then
returns” indicates that there is a
charging current applied to a condenser.
The needle will then remain at “∞ ”
unless the condenser is discharged.
＊
