FUEL PUMP INSTALLATION
Install the fuel pump and secure it with the
two bolts.
Connect the fuel pump inlet, outlet and
vacuum tubes.
Install the seat, met-in box and frame center
cover.
Measure the fuel pump output.
Start the engine and disconnect the fuel
outlet tube and place a clean container under
the tube to check the fuel output.
Output: 40cc/1500rpm/10 seconds .
FUEL TANK REMOVAL
Remove the floor board. (
!
2-4)
Remove the leg shield . (
!
2-5)
Disconnect the fuel unit wire connector.
Remove the fuel tube between the fuel tank
and the fuel filler.
Disconnect the fuel vapor tube.
Remove the fuel tank.
The installation sequence is the reverse of
removal.
