•Before running the engine, make sure that the working area is well-ventilated.
Never run the engine in a closed area. The exhaust contains poisonous carbon
monoxide gas which may cause death to people.
•Gasoline is extremely flammable and is explosive under some conditions. The
working area must be well-ventilated and do not smoke or allow flames or
sparks near the working area or fuel storage area.
SPECIFICATIONS
ENGINE
Throttle grip free play : 2_ 6mm
Spark plug : NGK: DPR7EA9
Spark plug gap : 0.9mm
Valve clearance : IN: 0.1mm EX: 0.1mm
Idle speed : 1600rpm
Engine oil capacity: Cylinder compression : 15±2kg/cm_
At disassembly : 1.1 liter Ignition timing : BTDC 10°±3°/1500rpm
At change : 0.9 liter Coolant capacity : 1165cc
Gear oil capacity : Radiator capacity : 825cc
At disassembly : 0.20 liter Reserve tank capacity : 340cc
At change : 0.18 liter
CHASSIS
Front/rear brake free play: 20_ 30mm
TIRE
