13. FUEL SYSTEM/CARBURETOR/
FUEL PUMP/ FUEL TANK
13-9
Bet & Win 1 25/1 50
FLOAT CHAMBER DISASSEMBLY
Remove the four float chamber screws and
the float chamber.
Remove the float pin, float and float valve.
FLOAT VALVE INSPECTION
Inspect the float valve seat contact area for
wear.
Float Chamber
Float Valve
Float
Float Pin
Float Valve Seat
Screws
Float Valve
