FINAL REDUCTION GEAR OIL
Stop the engine and remove the oil check bolt.
The oil level shall be at the oil check bolt hole.
If the oil level is low, add the recommended
oil SAE90# to the proper level.
Install the oil check bolt.
OIL CHANGE
Remove the oil check bolt.
Remove the oil drain bolt and drain the oil
thoroughly.
Install the oil drain bolt.
Torque: 9.8N-m
Fill the final reduction with the recommended
oil SAE90#.
Gear Oil Capacity:
At disassembly : 200cc
At change : 180cc
Reinstall the oil check bolt and check for oil
leaks.
DRIVE BELT
Remove the left crankcase cover.
Inspect the drive belt for cracks or excessive
wear.
Replace the drive belt with a new one if
necessary and in accordance with the
Maintenance Schedule.
