KYMCO ZX/SCOUT 50 User Manual

10. CRANKCASE/CRANKSHAFT
10-5
ZX / SCOUT
Measure the crankshaft runout.
Service Limit
A B
0.150mm
replace if over
0.100mm
replace if over
Check the crankshaft bearings for excessive
play. The bearings must be replaced if
they are noisy or have excessive play.
CRANKSHAFT INSTALLATION
Wash the crankshaft in cleaning solvent and
then check for cracks or other faults.
Play
Play
Radial
Axial
