11. CARBURETOR
11-8
ZX / SCOUT
AUTO BYSTARTER INSTALLATION
Install the auto bystarter into the carburetor
body until it bottoms..
Install the set plate and then tighten the two
screws.
FLOAT CHAMBER
Remove the two float chamber screws and
the float chamber.
Remove the screw and O-ring.
Remove the float pin, float and float valve.
Screws
Auto Bystarte
r
Set Plate
Screws
Float Pin
O-ring
Floa
t
