11. CARBURETOR
11-12
ZX / SCOUT
REED VALVE
REMOVAL
Remove the rear carrier.
Remove the frame body cover.
Remove the four intake manifold bolts and
gasket.
Remove the reed valve and gasket.
INSPECTION
Check the reed valve for damaged or weak
reeds.
Check the reed valve seat for cracks,
damage or clearance between the seat and
reed.
Replace the valve if necessary.
INSTALLATION
Install the reed valve in the reverse order of
removal.
Bolts
Intake Manifold
Reed Stoppe
