Kyocera ECOSYS M3540dn Service Manual

2NM/2NX/2NY/2NZ/2P0/2P6
1-4-19
(7) Electrical parts that could cause paper jam at the transfer , the fuser and the eject
parts
Timing of detection
Corrective Action
Jam code
J4201,J4211
Related parts
Eject sensor (ES) Control PWB (CONPWB)
Registration clutch (RCL) Connect right PWB (C-RPWB)
Main motor (MM)
Connect left PWB (C-LPWB)
Eject motor (EM)
Checking
procedure at the
occurrence of
J4201/J4211
Corrective action at the occurrence
On/Off control signal output connector
(terminal), point of checking connection
1 Items for Initial Checks See page 1-4-9
2
Eject sensor (ES) : Conduct connectivity
check, mounting location check,
operation check
CONPWB YC26-1
3
Control PWB : Replace
4
Registration clutch (RCL)
: Operation
check (U032)
C-RPWB YC12-6
5
Main motor : Operation check C-RPWB YC10-1/2/3/4
6
Connect right PWB : Replace
7
Eject motor : Operation check C-LPWB YC12-1/2/3/4
8
Connect left PWB : Replace

Kyocera ECOSYS M3540dn Specifications

General

Print Technology	Laser
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Scan Type	Color CIS
Scan Resolution	600 x 600 dpi
Fax Capability	Yes
Fax Transmission Speed	33.6 kbps
Paper Capacity	500 sheets
Connectivity	USB, Ethernet
Copying	Yes
Scanning	Yes
Modem Speed	33.6 kbps
Standard Input Capacity	500 sheets
Standard Output Capacity	250 sheets
Maximum Output Capacity	250 sheets
Maximum Print Size	A4
Standard Interfaces	USB 2.0, Ethernet
Ethernet LAN	Yes
Internal Memory	512 MB
Power Consumption (typical)	661 W
Display	LCD
Functions	Print, Copy, Scan, Fax
Operating System Compatibility	Windows, Mac OS, Linux
Print Speed	40 ppm (pages per minute)
Copy Speed	40 cpm (copies per minute)
Standard Paper Tray Media Types	Recycled
Maximum Internal Memory	1, 536 MB
Weight	22 kg
Product Colour	Black
