Kyocera FS-1118MFP Service Manual

2GM
1-6-29
Screws
Screws
Screw
Connectors
Screw
LSU shield
1
3
4
2
1-6-11 Removing the laser scanner unit and the eraser lamp
1. Remove the scanner unit (see page 1-6-27).
2. Remove two screws and then remove
grounding plate.
3. Remove each two screws and then remove
the right and left scanner stays.
Figure 1-6-32 Removing the right and left stays
4. Remove four connectors.
5. Remove six screws and then remove the LSU
shield.
* When refitting the LSU shield, tighten a
screw in order of 4 from 1.
Figure 1-6-33 Removing the LSU shield
Screws
Right scanner stay
Left scanner stay
Screws
Screws
Grounding plates

Kyocera FS-1118MFP Specifications

General

Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Fax memory	6 MB
Modem speed	33.6 Kbit/s
Dimensions (WxDxH)	496 x 421 x 385 mm
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Networking features	TCP/IP
All-in-one functions	Scan
Standard media sizes	60-105 g/m2, A4, B5, A5, A6, Letter, Legal, Folio 50-sheet multi-purpose tray, 60-163 g/m2, A4, B5, A5, A6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm), envelopes
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98, 98SE, ME, 2000, XP, NT 4.0
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Internal memory	96 MB
Processor model	750CXr
Processor family	PowerPC
Built-in processor	Yes
Maximum internal memory	320 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	65 dB
Bundled software	Paper Port Deluxe 9.2
Grayscale levels	256
Certification	TÜV/GS, CE
Maximum duty cycle	10000 pages per month
Power consumption (standby)	76 W
Power consumption (PowerSave)	40 W
Power consumption (average operating)	409 W
Market positioning	Home & office
