Kyocera FS-1118MFP Service Manual

2GM
1-5-25
Clean with isopropyl alcohol.
Check visually and replace any deformed
rollers (see pages 1-6-5, 6).
See pages 1-5-22, 23.
Clean with isopropyl alcohol.
See page 1-5-23.
Repair or replace if necessary .
See page 1-5-22.
Check the cassette claw visually and cor-
rect or replace if necessary.
Change the paper.
Check visually and replace any deformed
guides.
Check visually and remedy if necessary.
Clean or replace the press roller.
Repair if any springs are off the separation
claws.
Grease the bearings and gears.
Correct.
(1)
No primary paper feed.
(2)
No secondary paper
feed.
(3)
Skewed paper feed.
(4)
The scanner does not
travel.
(5)
Multiple sheets of paper
are fed at one time.
(6)
Paper jams.
(7)
Abnormal noise is
heard.
Check if the surfaces of the feed roller and
MP feed roller are dirty with paper powder.
Check if the feed roller and MP feed roller
are deformed.
Electrical problem with the feed clutch and
MP feed clutch.
Check if the surfaces of the upper and lower
registration rollers are dirty with paper pow-
der.
Electrical problem with the registration
clutch.
Deformed width guide in a cassette.
The scanner motor malfunctions.
Deformed cassette claw.
Check if the paper is curled.
Deformed guides along the paper conveying
path.
Check if the contact between the upper and
lower registration rollers is correct.
Check if the press roller is extremely dirty or
deformed.
Check if the contact between the heat roller
and its separation claws is correct.
Check if the rollers and gears operate
smoothly.
Check if the following electromagnetic
clutches are installed correctly: feed clutch,
MP feed clutch and registration clutch.
Problem Causes/check procedures Corrective measures
1-5-5 Mechanical problems

Kyocera FS-1118MFP Specifications

General

Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Fax memory	6 MB
Modem speed	33.6 Kbit/s
Dimensions (WxDxH)	496 x 421 x 385 mm
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Networking features	TCP/IP
All-in-one functions	Scan
Standard media sizes	60-105 g/m2, A4, B5, A5, A6, Letter, Legal, Folio 50-sheet multi-purpose tray, 60-163 g/m2, A4, B5, A5, A6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm), envelopes
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98, 98SE, ME, 2000, XP, NT 4.0
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Internal memory	96 MB
Processor model	750CXr
Processor family	PowerPC
Built-in processor	Yes
Maximum internal memory	320 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	65 dB
Bundled software	Paper Port Deluxe 9.2
Grayscale levels	256
Certification	TÜV/GS, CE
Maximum duty cycle	10000 pages per month
Power consumption (standby)	76 W
Power consumption (PowerSave)	40 W
Power consumption (average operating)	409 W
Market positioning	Home & office
