Kyocera FS-1118MFP Service Manual

Maintenance
Description
item No.
2GM
1-4-12
U161 Setting the fusing control temperature
Description
Changes the fusing control temperature.
Purpose
Normally no change is necessary. However, can be used to prevent curling or creasing of paper, or solve a
fusing problem on thick paper.
Method
Press the enter key. A selection item appears.
Setting
1. Select the item to be set using the up/down cursor keys.
2. Change the setting using the left/right cursor keys.
Display Description Setting range Initial setting
First Temp. Primary stabilization fusing temperature 100 to 165 (°C) 135
Second Temp. Secondary stabilization fusing temperature 100 to 165 (°C) 160
Copy Temp. 1 Printing operation temperature 1 160 to 220 (°C) 190
Copy Temp. 2 Printing operation temperature 2 160 to 220 (°C) 195
Temp. 1 Cont. # Number of sheets for fusing control 1 to 99 5
Printing operation temperature 1: Temperature in printing operation at the start of printing
Printing operation temperature 2: Temperature in printing operation after the specified number of sheets for
fusing control have passed
Number of sheets for fusing control: The number of sheets to be counted for switching from printing
operation temperature 1 to printing operation temperature 2
The temperatures are to be set such that Secondary stabilization
>
=
Primary stabilization.
3. Press the enter key. The value is set.
Completion
Press the back key. The indication for selecting a maintenance item No. appears.
U163 Resetting the fusing problem data
Description
Resets the detection of a service call code indicating a problem in the fusing section.
When a service call concerning the fusing section occurs, turn the power switch off and open the front cover.
Then, turn the power switch on and press the system menu/counter key to enter the maintenance mode.
Purpose
To prevent accidents due to an abnormally high fusing temperature.
Method
1. Press the enter key. A selection item appears.
2. Select Execute using the up/down cursor keys.
3. Press the enter key. The fusing problem data is initialized. (Four service calls, namely C6000, C6020,
C6050, and C6400 are reset.)
Completion
Press the back key. The indication for selecting a maintenance item No. appears.

Kyocera FS-1118MFP Specifications

General

Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Fax memory	6 MB
Modem speed	33.6 Kbit/s
Dimensions (WxDxH)	496 x 421 x 385 mm
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Networking features	TCP/IP
All-in-one functions	Scan
Standard media sizes	60-105 g/m2, A4, B5, A5, A6, Letter, Legal, Folio 50-sheet multi-purpose tray, 60-163 g/m2, A4, B5, A5, A6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm), envelopes
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98, 98SE, ME, 2000, XP, NT 4.0
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Internal memory	96 MB
Processor model	750CXr
Processor family	PowerPC
Built-in processor	Yes
Maximum internal memory	320 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	65 dB
Bundled software	Paper Port Deluxe 9.2
Grayscale levels	256
Certification	TÜV/GS, CE
Maximum duty cycle	10000 pages per month
Power consumption (standby)	76 W
Power consumption (PowerSave)	40 W
Power consumption (average operating)	409 W
Market positioning	Home & office
