2GM
1-4-2
General
Initialization
Drive, paper
feed and paper
conveying
system
Optical
High voltage
Developing
Fusing and
cleaning
Operation
panel and
support
equipment
Mode setting
processing
Others
U000 Outputting an own-status report
U020 Initializing all data
U034 Setting paper timing
Adjusting the leading edge registration
Adjusting the center line
U051 Adjusting the amount of slack in the paper 0
U060 Adjusting the scanner input properties 12
U063 Adjusting the shading position 0
U065 Adjusting the scanner magnification
Main scanning direction 0
auxiliary scanning direction 0
U066 Adjusting the leading edge registration for scanning an original on the 6
contact glass
U067 Adjusting the center line for scanning an original on the contact glass 7
U070 Adjusting the DP magnification –2
U071 Adjusting the DP scanning timing
Adjusting leading edge registration 11
Adjusting trailing edge registration 0
U072 Adjusting the DP center line -0.7
U074 Adjusting the DP input light luminosity 1
U087 Turning the DP scanning position adjust mode on/off 35
U089 Outputting a MIP-PG pattern
U101 Setting the other high voltages 26/55/48/
43/24/60
U130 Initial setting for the developer OFF
U144 Setting toner loading operation 1
U157 Checking/clearing the developing drive time
U161 Setting the fusing control temperature
Primary stabilization fusing temperature 135
Secondary stabilization fusing temperature 160
Copying operation temperature 1 190
Copying operation temperature 2 195
Number of sheets for fusing control 5
U163 Resetting the fusing problem data
U203 Operating DP separately
U207 Checking the operation panel keys
U260 Changing the copy count timing
U403 Adjusting margins for scanning an original on the contact glass
U404 Adjusting margins for scanning an original from the DP
U411 Adjusting the scanner automatically
U425 Setting the target
U901 Checking/clearing print counts by paper feed locations
U905 Checking/clearing counts by the DP
U911 Checking/clearing print counts by paper size
U927 Clearing accounting counter
U928 Checking/clearing the machine life count
* Initial setting for executing maintenance item U020
Category
Item
Maintenance
Initial
No. setting*
(2) Maintenance modes
