Kyocera FS-1118MFP Service Manual

2GM
1-5-24
Problem Causes Check procedures/corrective measures
(13)
Main charging is not
performed.
(14)
Transfer charging is
not performed.
(15)
A paper jam in the
paper feed or exit
section is indicated
when the power
switch is turned on.
(16)
The message re-
questing cover to be
closed is displayed
when the front cover
is closed.
(17)
Others.
Broken main charger wire.
Leaking main charger
housing.
Poor contact in the high
voltage PWB connector
terminals.
Defective engine PWB.
Defective high voltage
PWB.
Poor contact in the high
voltage PWB connector
terminals.
Defective engine PWB.
Defective high voltage
PWB.
A piece of paper torn from
paper is caught around
registration sensor or exit
sensor.
Defective registration sen-
sor.
Defective exit sensor.
Poor contact in the con-
nector terminals of inter-
lock switch.
Defective interlock switch.
Wiring is broken, shorted
or makes poor contact.
Noise.
See page 1-5-16.
See page 1-5-16.
Check and remove if any.
Check if YC8-7 on the engine PWB remains low when the regis-
tration sensor is turned on and off. If it does, replace the regis-
tration sensor.
Check if YC7-7 on the engine PWB remains low when the exit
sensor is turned on and off. If it does, replace the exit sensor.
Reinsert the connector. Also check for continuity within the con-
nector cable. If none, remedy or replace the cable.
Check for continuity across switch. If there is no continuity when
the switch is on, replace it.
Check for continuity. If none, repair.
Locate the source of noise and remove.

Kyocera FS-1118MFP Specifications

General

Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Fax memory	6 MB
Modem speed	33.6 Kbit/s
Dimensions (WxDxH)	496 x 421 x 385 mm
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Networking features	TCP/IP
All-in-one functions	Scan
Standard media sizes	60-105 g/m2, A4, B5, A5, A6, Letter, Legal, Folio 50-sheet multi-purpose tray, 60-163 g/m2, A4, B5, A5, A6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm), envelopes
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98, 98SE, ME, 2000, XP, NT 4.0
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Internal memory	96 MB
Processor model	750CXr
Processor family	PowerPC
Built-in processor	Yes
Maximum internal memory	320 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	65 dB
Bundled software	Paper Port Deluxe 9.2
Grayscale levels	256
Certification	TÜV/GS, CE
Maximum duty cycle	10000 pages per month
Power consumption (standby)	76 W
Power consumption (PowerSave)	40 W
Power consumption (average operating)	409 W
Market positioning	Home & office
