Kyocera FS-1118MFP Service Manual

2GM
1-5-7
Problem Causes/check procedures Corrective measures
• DP
(1)
An original jams
when the power
switch is turned on.
(2)
An original jams in
the DP is indicated
during copying (no
original feed).
Jam code 70
(3)
An original jams in
the DP during copy-
ing (a jam in the
original conveying
section).
Jam code 71
(4)
Original jams fre-
quently.
A piece of paper torn from
an original is caught
around the DP timing
switch.
Defective DP timing
switch.
Defective DP timing
switch.
Check if the forwarding
pulley or feed pulley is de-
formed.
Defective DP timing
switch.
Check if the conveying
roller or exit roller is de-
formed.
An original outside the
specifications is used.
The forwarding pulley or
feed pulley is dirty with pa-
per powder.
The conveying roller and
conveying pulleys do not
contact correctly.
The exit roller and exit pul-
leys do not contact cor-
rectly.
Remove any found.
Check if YC10-6 on the engine PWB remains low when the DP
timing switch is turned on and off. If it does, replace the DP tim-
ing switch.
Check if YC10-6 on the engine PWB remains low when the DP
timing switch is turned on and off. If it does, replace the DP tim-
ing switch.
Check visually and replace the deformed pulley.
Check if YC10-6 on the engine PWB remains low when the DP
timing switch is turned on and off. If it does, replace the DP tim-
ing switch.
Check visually and replace the deformed roller.
Use only originals conforming to the specifications.
Clean with isoproply alcohol.
Check and remedy.
Check and remedy.

Kyocera FS-1118MFP Specifications

General

Print technology	Laser
Maximum resolution	1800 x 600 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	18 ppm
Fax memory	6 MB
Modem speed	33.6 Kbit/s
Dimensions (WxDxH)	496 x 421 x 385 mm
Power requirements	AC 220 ~ 240 V, 50/60 Hz
Networking features	TCP/IP
All-in-one functions	Scan
Standard media sizes	60-105 g/m2, A4, B5, A5, A6, Letter, Legal, Folio 50-sheet multi-purpose tray, 60-163 g/m2, A4, B5, A5, A6, Letter, Legal, Folio, Custom (105 x 148 to 216 x 356 mm), envelopes
Color all-in-one functions	scan, n
Compatible operating systems	Windows 98, 98SE, ME, 2000, XP, NT 4.0
Total input capacity	250 sheets
Total output capacity	150 sheets
Maximum input capacity	550 sheets
Maximum print size	210 x 297 mm
Maximum ISO A-series paper size	A4
Internal memory	96 MB
Processor model	750CXr
Processor family	PowerPC
Built-in processor	Yes
Maximum internal memory	320 MB
Sound power level (standby)	43 dB
Sound pressure level (printing)	65 dB
Bundled software	Paper Port Deluxe 9.2
Grayscale levels	256
Certification	TÜV/GS, CE
Maximum duty cycle	10000 pages per month
Power consumption (standby)	76 W
Power consumption (PowerSave)	40 W
Power consumption (average operating)	409 W
Market positioning	Home & office
