Lamtec CMS User Manual

106
5 Functional Description with Process Diagrams
5.4.3.6 Burner Shut-OFF
P no. Description Attributes
44 Start-up sequence: firing-rate [Digit] V1.0.0.0
Start-up output in digit depending on internal firing-rate.
Enter the burner firing-rate with which the burner shall start in the start-up sequence.
Write: 0/GUI/UI
Read: 0
Default: 0
Min: 0
Max:999
45 Start-up sequence: start-up time [s] V1.0.0.0
Start-up time in s
Enter the maximum duration, during which the start-up sequence should effect.
Write: 0/GUI/UI
Read: 0
Default: 1
Min: 0
Max:32767
46 External firing-rate limit [Digit] V1.0.0.0
External firing-rate limit in digit depending on the internal firing-rate.
Only for activated burner firing-rate controller.
Write: 0/GUI/UI
Read: 0
Default: 999
Min: 0
Max:999
P no. Description Attributes
47 Soft stop time  burner run-out time [s] V1.0.0.0
Currently without function. Write: 0/GUI/UI
Read: 0
Default: 0
Min: 0
Max:100
54 switch-on threshold V1.0.0.0
Switch-off hysteresis for the lower control range
If the actual value falls below the setpoint minus the value set in this parameter, the burner is
switched on again.
Enter the switch-on point as the difference to the setpoint.
Switch on value = setpoint value - parameter content.
Example: The burner shall start at 110.
Setpoint value = 120, parameter value = 10, switch-on point = 120 - 10 = 110.
If the burner should switch on again above the setpoint, negative values can also be
entered. Thereby corresponds -1 = 65535 and -999 = 64537.
Parameter content = 65536 - difference.
Example: The burner shall start at 125.
Setpoint value = 120, parameter value = 65536 - 5 = 65531, switch-on point = 120 - (-5) =
125.
Write: 0/GUI/UI
Read: 0
Default: 1
Min: -32768
Max: 32767
55 Switch-off threshold for the upper control range V1.0.0.0
Switch-off hysteresis of the upper control range in °C or bar (x.xx)
Input of the upper control range. If the actual value exceeds the setpoint by this value, the
burner runs at base fire.
The value entered corresponds to the difference between the current setpoint and the upper
limit of the control range. Depending on the setting in P 61, the content is interpreted as °C
(directly without decimal point) as bar (resolution 0.1 bar - range 0.1 to 99.9 bar) or in digits.
Write: 0/GUI/UI
Read: 0
Default: 5
Min: 0
Max:999
