LEGRAND D45 SYSTEM User Manual

Diagram 9
A
To install alternative internal units, refer to
wiring variant section.
B
To install alternative Entrance panel, refer to
wiring variant section.
Device configuration by SF2 software.
C
Set internal IMPEDANCE SWITCH to ON.
D
Physical configuration or advanced configuration by
software MHSUITE.
 Configure and insert the jumpers with the system
SWITCHED OFF. Also every time the configuration is
modified the pws must be switched OFF and ON again,
waiting about 1 minute.
WARNINGS:
system witH d45 interface and software switcHboard
D
C
B
B DCA
+
– –
+
BUS
F F I I #I #I F F I I #I #I
1 2
BUSBUS
321070 321070
323002
323005
322011
0 1 0 1 0 1 0 4
L + +12L – UNLOCK
PBL1
LAN SYSTEM1
SYSTEM2
WEP
DCV OUT GAIN
Speed Full Link Aux System
323011
323011
B DCA
+
– –
+
BUS
323005
322011
L + +12L – UNLOCK
PBL1
LAN SYSTEM1
SYSTEM2
WEP
DCV OUT GAIN
Speed Full Link Aux System
323011
323011
B DCA
+
– –
+
BUS
323005
322011
L + +12L – UNLOCK
PBL1
LAN SYSTEM1
SYSTEM2
WEP
DCV OUT GAIN
Speed Full Link Aux System
323011
323011
B DCA
+
– –
+
323005
ON
SD
1
2
3
4
ON
SD
1
2
3
4
323003
Ethernet Switch
ITEM DEscrIPTION
322011
Digital call entrance panel
323011 D45/IP interface
323005 Main power supply
323002 Floor shunt
321070 7" Touch screen internal unit
323003 Riser shunt
323012 Softswitchbard for Laptop
L1 Electric door lock 12V - 4A impulsive
PB Door lock release pushbutton
Laptop
WIRING DIAGRAMS
92
